DOUBLE SIDE PLANER QMB206F-GH
Introduction:
Professional solution: double-side planing, fit for large scale, high efficient and mass production.
Configurate the spiral cutter spindles, hard tooth surface reduction box and international brand frequency converter, ensuring the high speed cutting, stable performance and high efficiency.
Inquire Now
Product Details
| Specifications | QMB206F-H | |
| Working width | mm | 50~630 |
| Working thickness | mm | 10~ 170 |
| Min.working length | mm | 310 |
| Max cutting depth (Upper\Botom) | mm | 5\3 |
| Feeding speed | m/min | 10~40 |
| Rotation speed of spindle | r/min | 5800 |
| Spindle cutting dia | mm | Φ135 |
| Total power | kW\HP | 30.8\41 |
| Spindle motor | kW\HP | \ |
| Top spindle motor | kW\HP | 15\20 |
| Bottom spindle motor | kW\HP | 11\ 15 |
| Front blade spindle motor | kW\HP | \ |
| Back blade spindle motor | kW\HP | \ |
| Feeding motor | kW\HP | 4 \5.5 |
| Lifting motor | kW\HP | 0.75\ 1 |
| Suction hood Dia | mm | 4xΦ150 |
| Overall dimensions | mm | 3120x1180x1830 |
| Weight | kg | 3600 |
