FLOATING PRIMER SANDING MACHINE SFR-R-1300V
Introduction:
Professional solution: Pre-treatment of materials and priming (sanding before painting).
The ball screw is used to synchronously adjust the lifting mechanism, the sand cutting speed can be adjusted, the sand belt is clean and equipped with electric swing blowing device, easy to operate and high precision.
Inquire Now
Product Details
| Specifications | SFR-R1300V | |
| Sand cutting width | mm | 40~1300 |
| Sand cutting thickness | mm | 3~100 |
| The shortest sand cutting length | mm | 300 |
| Planer shaft speed | m/s | \ |
| Speed of the first group of sanding belt | m/s | \ |
| Speed of the second group of sanding belt | m/s | \ |
| Speed of the third group of sanding belt | m/s | \ |
| Feeding speed | m/min | 3~25 |
| Sanding belt size | mm | 1370x2100 |
| Total motor power | kW\HP | 29.2\39 |
| Planer shaft motor | kW\HP | \ |
| The first group of belt motor | kW\HP | 11\15 |
| The second group of belt motor | kW\HP | 11\15 |
| The third group of belt motor | kW\HP | \ |
| Feeding motor | kW\HP | 2.2\3 |
| Vacuum adsorption brush motor | kW\HP | 4\5.5 |
| Dust brush motor | kW\HP | 0.37\0.5 |
| Workbench lifting motor | kW\HP | 0.55\0.7 |
| Vacuum port diameter | mm | 3xΦ180+3xΦ150 |
| Working pressure | MPa | 0.6 |
| Machine dimensions | mm | 2100x2050x2300 |
| Machine weight | kg | 3800 |
