Product Details
| 参数项 | 值 | 参数项 | 值 | |
| 行程 | X | 2900mm | 加工范围 | 1100× 1300×700mm |
| Y | 1300mm | 主轴 | 9kW、ISO30自动换刀主轴 | |
| Z | 900mm | 刀库 | 8把斗笠式刀库 | |
| Y2 | 1300mm | 工作台 | 固定铝型材+真空吸附 | |
| B | ±100° | 控制系统、伺服 | 台湾新代 | |
| 快移速度 | X | 45m/min | 导轨、丝杆 | 台湾HIWIN、台湾ABBA |
| Y | 40m/min | 减速机 | 日本新宝 | |
| Z | 20m/min | 齿轮齿条 | 台湾精特 | |
| Y2 | 40m/min | 电器 | 施耐德 | |
| B | 15r/min | 外形尺寸 | 4900×2300×2800mm | |
| 整机重量 | 约3000kg |
Product features：
1.The beams and key structural parts have undergone finite element analysis, stress relief annealing, and vibration aging treatment. The key part is processed by the gantry machining center at one time.
2.The machine is equipped with a 9kW automatic tool change spindle, an 8-position tool magazine, and the maximum speed of the spindle is 18000RPM.
3.The machine has two workbenches, with two working modes, single-action and linkage.
4.The workbench is made up of spliced aluminum profiles and is equipped with a vacuum suction interface.
5.SYNTEC CNC system from Taiwan, easy to learn.
