PLANER AND SANDER MACHINE SPR-RP1300

Introduction:

Professional solution: Planing and fine sanding for solid wood finger joint board,etc.

One machine for both planing and sanding;high quality,high effciency and high table performance.

Inquire Now

Product Details

Specifications		SPR-RP1300
Sand cutting width	mm	40~1300
Sand cutting thickness	mm	3~120
The shortest sand cutting length	mm	520
Planer shaft speed	m/s	36
Speed of the first group of sanding belt	m/s	19
Speed of the second group of sanding belt	m/s	18.5
Speed of the third group of sanding belt	m/s	\
Feeding speed	m/min	6~30
Sanding belt size	mm	1330x2200
Total motor power	kW\HP	77.1\103
Planer shaft motor	kW\HP	22\30
The first group of belt motor	kW\HP	30\40
The second group of belt motor	kW\HP	18.5\25
The third group of belt motor	kW\HP	\
Feeding motor	kW\HP	5.5\7.5
Vacuum adsorption brush motor	kW\HP	\
Dust brush motor	kW\HP	0.37\0.5
Workbench lifting motor	kW\HP	0.75\1
Vacuum port diameter	mm	9xΦ150
Working pressure	MPa	0.6
Machine dimensions	mm	2850x2050x2200
Machine weight	KG	5150
