RIP SAW QMJ-164A BOTTOM SPINDLE
Introduction:
Professional solution: used to cut the flat wood into two pieces in one time or trim the long edge.
Equipped with casting chain plates and guide track with special material and special design.And the saw spindle is bottom type.Safe operation, stable performance and high processing quality.
Inquire Now
Product Details
| Specifications | QMJ164A\A-T | |
| Maximum sawing thickness | mm | 120 |
| Minimum sawing length | mm | 120（修边250） |
| Deep throat | mm | 660 |
| Saw shaft diameter | mm | Φ50.8 |
| Saw shaft speed | r/min | 3000 |
| Saw blade diameter | mm | Φ355~Φ455 |
| Feeding speed | m/min | 6~30 |
| Total motor power | kW\HP | 13.2\ 18 |
| Main motor | kW\HP | 11\ 15 |
| Feeding motor | kW\HP | 2.2\3 |
| Lifting motor | kW\HP | 0.37\0.5optional |
| Suction hood Dia | mm | Φ150+Φ120 |
| Overall dimensions | mm | 2250x1680x1550 |
| Weight | kg | 1950 |
